BMW E92 335i – BMW Performance

BMW E92 N55 335i – All About BMW Performance Parts

All our customer projects have a set of objectives, and often a theme, and this one is no exception. This customer wanted a stunning, show quality car, that also had some more GO to it to complement its looks. We would often then select from a wide diversity of our quality suppliers, but this time, the customer wanted to go mostly the OEM route. BMW is one of the few car manufacturers that has decided to get into the aftermarket performance parts market. They delved into the market in about 2008, and have been expanding their offerings each year. The BMW E9x 335i came out in 2007, and was a perfect target for BMW to develop and expand their BMW Performance product offerings. They now have products that tick most of the normal upgrade boxes: (1) engine performance, (2) wheels, (3) exterior body enhancements (4) exhaust (5) interior enhancements. Our customer would take advantage of almost all of these from BMW Performance in this project, plus add those additional elements to truly make this project complete.

Interior

You think the interior on a BMW is nice to begin with, but BMW Performance offers some nice upgrade options. The customer elected to have the full Carbon Fiber (CF) interior trim set added. This is a very high quality CF kit, not one that you need to worry about the clear coat fading or cracking over time, or the original quality not matching the original OEM look and fit. Fit is perfect, the look is stunning, and the kit includes the front dash, the door trim elements, and the complete center console (front and rear sections).

BRR BMW inter

IMG_6673

IMG_6679

IMG_6782

BMW Performance has gone one step farther than just doing the interior trim. They have created several different performance steering wheels. You can get just a standard steering wheel w alcantara cover, or a different shaped steering wheel w alcantara covering, or even one with built-in shift lights and data display. Our customer wanted the full effect, and selected the BMW steering wheel w alcantara and data display. The steering wheel also offers the option to have the center element of the steering wheel (normally thought of as the multi-function area) also covered in alcantara. Again, the fit is perfect, the electronics are all “plug and play”, you maintain the airbag feature, and the feel is something you cherish every time you drive the car. (NOTE – you’ll see in the images below, we had completed the steering wheel install after the interior trim, but before the center console section, which was done later).

IMG_5914

IMG_5915

EXTERIOR

If we are going to do the interior, then, as a complete project, we need to upgrade the exterior as well. BMW Performance parts are available for the exterior as well, including the front spoiler / splitter, front grills, rear trunk lip spoiler, and rear diffuser. To these, we added some more elements: front body colored side markers, matching front BMW hood emblem in all black.

IMG_6767

IMG_6768

IMG_6769

One piece that is just REALLY cool, and simple, but adds that full BMW OEM touch is the door light. This is the light in the base of the door, that when the door is open, displays and lights up the ground, to help you see at night and make getting in and out of the car easier. But, rather than just have a standard LED light, you can now have the BMW Roundel emblem display on the ground….how cool is that??

IMG_6781

The car is a later model E92…or called the E92 LCI version, so the car came with the newer LED rear tail lights.

IMG_6778

Therefore, we needed to add the upgraded (aftermarket) LED angel eyes to match the lighting look of the car.

IMG_6780

Engine Bay – Trim

This element is not about performance, this is about WHAM! The “oh my gosh” type of upgrade, that truly makes the project unique and amazing. There are lots of intakes for the BMW N55 engine. Most look like they do something, but don’t really help. Some represent themselves as “cold air intakes” (CAI), but actually are worse than stock. The original BMW engine intake comes w air scopes positioned right above the radiator, to help direct that forced, cold air into the intake system. So, if you instead implement an air intake that is only exposed air filters in the engine bay, and you know that the BMW Turbo engine puts out a lot of heat..how is that supposed to help. So, we wanted a truly functional cold air intake, but also one that would look the part of the rest of the car. Conversely, if you ask most BMW owners what the nicest looking intake system on the market is, they will say Gruppe M. Most don’t want to pay the price tag for the Gruppe M system, but this project cried out for just that. The system is functional, is a true cold air system, and just is STUNNING in its looks. To make this even more functional, we added a set of RPi front intake scoops. A turbo engine gets hungry for air, we needed to feed the beast that lies within.

IMG_5912

IMG_5913

IMG_6671

IMG_6672

PERFORMANCE

Staying with the BMW Performance parts catalog approach, the easy first step was to select the BMW Performance Power Kit. The kit includes updated engine management software and some additional cooling elements to properly maintain the cool of the engine. The good news about this type of approach, is that you maintain the BMW warranty, and for California customers, you get the of so needed “CARB” sticker for state compliance. If you go the BMW Power Kit approach, you do get a good jump in power, but not as much as some of the aftermarket tunes. So, we wanted the best of both worlds, so decided to add those natural other elements to help the engine perform better within the parameters of the new BMW tune….lets keep the turbo charge cool –> meaning, lets add a bigger and better intercooler, and, lets help the turbo’s spin, spool, and not struggle to exhail –> downpipes. We choose the ER (Evolution RaceWerks) intercooler. There are several facets / features to concern yourself with when selecting an intercooler…and its not just which one is the biggest, or the deepest. The specific factors are those that have the best drop in incoming vs outgoing “delta T” values (biggest drop in air charge temperature drop), and which ones at the same time, have the lowest “delta P” values. Lowest drop in pressure from entry to exit. On the “delta P” values, you need to think about more than just the measure across the radiator or heat exchanger section….where many IC’s get poorly implemented is in the end tanks and the flow into and out of the heat exchanger. For every change in flow direction, there is a loss in velocity and pressure….and a crude rule of thumb in CFD (computational fluid dynamics), is every 90 degree change in flow direction is a loss of 12% efficiency (we can put the CFD equation here if desired)….and another factor is the length of the pipe run. You will hear many manufacturers of how deep their IC is….that is not a critical element. We can even get into the design of the actual tubes within the IC and their effectiveness for heat transfer…..but, too much talk here about the engineering. The net….we like the ER IC and have used it in many cars w great results.

The next part is the downpipe. The OEM downpipe has CA legal catalytic convertors, so, flow thru the “cats” is not great. Also, BMW made the OEM pipes to be easy to install and easy to manufacture….the parameter of it being the best flowing pipe was not as high on their objective list. Our priority is a better flowing pipe….so, size, shape, and the cell count in the “cat” were critical. We have run “catless” pipes, but that was outside the parameters of this project, as we hope to be able to still pass CA smog requirements. The best down pipe in our view is the AR Design pipe. Not only is the quality, design tops, and fitment / clearance is great, but they think through the complete kit, including the upgraded exhaust gaskets.

Evolution RaceWerks Front Mount Intercooler (FMIC)

IMG_5118

BMW N54 Single Turbo AR Design “Down Pipe” – compared to the stock BMW version

IMG_5454

IMG_5455

IMG_5456

SUSPENSION

There are many ways to go w suspension. Almost all of them create new benefits, but often w a matching set of trade offs when it comes to street cars. If this were a pure track car, then the decisions become more guided by budget than product selection, but when we are dealing with a daily driven street car, too often the decision is made more in the direction of performance, but, with the car hardly ever able to exercise that feature, the draw back is not worth the price. BMW, when they designed the car made the car for the mass public, many of whom could care less about driving performance, really. But, at the same time, BMW realized that a segment of their customer base did indeed desire a higher level of driving experience, so they created the BMW Performance Suspension Kit. That is what we implemented for this car, a new set of sport springs (front and rear), a new set of performance struts / shocks, that are valved to match the upgraded spring rate of the new springs, and a stiffer anti-roll bar to keep the car flatter under cornering loads.

In driving, the kit achieves the objective…better, crisper handling, a slightly lower more aggressive stance, yet a ride that can still take the beating from our wonderful freeways and roads without breaking your back or the car.

IMG_6645

IMG_6658

IMG_6659

IMG_6661

IMG_6657

FINISHED PROJECT

IMG_6759

IMG_6760

IMG_6763

IMG_6766

IMG_6761

IMG_6767

IMG_6776

IMG_6770

IMG_6771

BRracing – creating EXCITMENT for our customers !!
